Metal Core PCB (Printed Circuit Board) is a type of PCB that uses a metal core as its base
material instead of the traditional FR-4 (Fiberglass Reinforced Epoxy). The metal core
provides excellent thermal conductivity, making it ideal for high-power applications.
However, to ensure the proper functioning of the PCB, it is essential to choose the right
dielectric material.

Dielectric materials are non-conductive materials that are used to separate the conductive
layers of a PCB. They provide electrical insulation and also help to maintain the signal
integrity of the circuit. In metal core PCBs, the dielectric material is sandwiched between
the metal core and the copper layer.

part area heavy copper pcb at same layer

There are several dielectric materials that can be used in metal core PCBs, but the most
commonly used ones are:

1. Polyimide (PI)

Polyimide is a high-temperature-resistant material that can withstand temperatures up to
400°C. It has excellent mechanical strength and is also resistant to chemicals and
radiation. Polyimide is an ideal choice for applications that require high-temperature
resistance and durability.

2. FR-4

FR-4 is a common dielectric material used in traditional PCBs. It is a fiberglass-
reinforced epoxy material that provides good electrical insulation and mechanical strength.
However, it has poor thermal conductivity, which makes it unsuitable for high-power
applications.

GET IN TOUCH!

3. Ceramic

Ceramic is a high-temperature-resistant material that provides excellent thermal
conductivity. It is also resistant to chemicals and radiation. Ceramic is an ideal choice
for high-power applications that require high-temperature resistance and good thermal
conductivity.

4. Thermal Interface Material (TIM)

TIM is a material that is used to improve the thermal conductivity between the metal core
and the copper layer. It is a thin layer of material that is placed between the metal core
and the copper layer. TIM helps to reduce the thermal resistance between the metal core and
the copper layer, which improves the thermal performance of the PCB.

Choosing the right dielectric material for a metal core PCB depends on the specific
requirements of the application. Factors such as temperature, power requirements, and
mechanical strength should be considered when selecting the dielectric material.

In conclusion, the dielectric material is an essential component of a metal core PCB. It
provides electrical insulation, maintains signal integrity, and helps to improve the
thermal performance of the PCB. The choice of dielectric material depends on the specific
requirements of the application. Polyimide, FR-4, ceramic, and thermal interface material
are some of the commonly used dielectric materials in metal core PCBs.
