Metal core PCBs (Printed Circuit Boards)

Metal core PCBs (Printed Circuit Boards) are becoming increasingly popular in the
electronics industry due to their superior thermal management capabilities. These PCBs have
a metal core layer that acts as a heat sink, dissipating heat generated by the components
on the board. This makes them ideal for use in high-power LED lighting, power supplies,
automotive and aerospace applications, and many other industries where heat management is
crucial.

The metal core layer in these PCBs is typically made of aluminum, copper, or a combination
of both. Aluminum is the most commonly used material due to its low cost and excellent
thermal conductivity. Copper, on the other hand, is more expensive but has better thermal
conductivity than aluminum. The choice of material depends on the specific application and
the budget of the project.

2 layers aluminum metal core pcb stack up

The metal core layer is sandwiched between the top and bottom layers of the PCB, which are
made of a non-conductive material such as fiberglass or ceramic. The metal core layer is
then connected to the other layers through vias, which are small holes drilled through the
board. The vias allow for the transfer of signals and power between the layers.

One of the main advantages of metal core PCBs is their ability to dissipate heat quickly
and efficiently. This is especially important in high-power LED lighting applications,
where the heat generated by the LEDs can cause them to fail prematurely. Metal core PCBs
can help extend the life of the LEDs by keeping them cool, which also improves their
performance and efficiency.

GET IN TOUCH!

Structure of Aluminum metal core pcb

Another advantage of metal core PCBs is their durability and resistance to vibration and
shock. This makes them ideal for use in automotive and aerospace applications, where the
PCBs may be exposed to harsh environments and extreme temperatures.

Metal core PCBs also offer better electromagnetic interference (EMI) shielding than
traditional PCBs. The metal core layer acts as a shield, preventing electromagnetic waves
from interfering with the signals on the board. This is important in applications where
signal integrity is critical, such as in telecommunications and medical devices.

Applications of Double sided metal Core PCB

Despite their many advantages, metal core PCBs are more expensive than traditional PCBs.
However, the cost is often justified by the improved performance and reliability they
offer. In addition, the cost of metal core PCBs has been decreasing in recent years due to
advancements in manufacturing technology and increased demand.

In conclusion, metal core PCBs are an excellent choice for applications where thermal
management, durability, and EMI shielding are important. They offer superior performance
and reliability compared to traditional PCBs and are becoming increasingly popular in a
wide range of industries. As the demand for high-performance electronics continues to grow,
metal core PCBs will undoubtedly play an important role in the future of electronics design
and manufacturing.
