Aluminum substrate material

The aluminum substrate is a thin layer of aluminum that is laminated onto a non-conductive material,

such as fiberglass or ceramic, to create a rigid and durable circuit board.

Aluminum substrate PCBs are commonly used in high-power LED lighting,

automotive electronics, and power electronics applications due to their excellent thermal conductivity and heat dissipation properties.

They are also known for their high mechanical strength, resistance to corrosion, and low cost compared to other substrate materials.

GET IN TOUCH!

What can be made of aluminum substrate materials

Aluminum substrate materials are commonly used in various electronic applications that require high thermal conductivity and heat dissipation.

Some of the products that can be made using aluminum substrate materials include:

1. LED lighting: Aluminum substrate materials are widely used in high-power LED lighting applications due to their excellent thermal conductivity and heat dissipation properties.

2. Automotive electronics: Aluminum substrate materials are used in the manufacturing of automotive electronics such as engine control units, power modules, and LED headlights.

3. Power electronics: Aluminum substrate materials are used in power electronics applications such as power supplies, inverters, and motor drives.

4. RF/microwave applications: Aluminum substrate materials are used in RF/microwave applications such as antennas, filters, and amplifiers.

5. Consumer electronics: Aluminum substrate materials are used in consumer electronics such as smartphones, tablets, and laptops to improve their thermal performance and extend their lifespan.

Overall, aluminum substrate materials are versatile and can be used in a wide range of electronic applications that require high thermal conductivity and heat dissipation.

AMB cermaic PCB process

What are the aluminum substrate materials

Aluminum substrate materials are typically made from aluminum alloys, such as 6061-T6, 5052-H32, or 3003-H14.

These alloys have varying levels of strength, corrosion resistance,

and other properties that make them suitable for different applications.

Other aluminum substrate materials include pure aluminum (aluminum 1100),

aluminum-copper alloys (aluminum 2024), and aluminum-magnesium alloys (aluminum 5083).
