How to distinguish via cover oil and via opening in the PCB printing process

ByGrace December 26, 2024December 24, 2024

Regarding the point of “via cover oil” and “via opening” (the difference between the usage of VIA and PAD), many customers and design engineers often ask what this means when placing orders on the system, and which option should I choose for my file? The following is an explanation of this issue:

I often encounter such problems.

The design is seriously non-standard. It is impossible to distinguish the usage of pad and via. Sometimes the conductive hole is processed with the attribute of pad, and sometimes the key hole is processed with the attribute of via. The design of VIA attribute and PAD attribute is chaotic, resulting in wrong processing. This is also one of the problems that often cause complaints. For circuit board production factories, when processing CAM data, some film processing engineers make mistakes because of the non-standard design files of customers. They help customers modify the files and make the non-standard design correct. They process the engineering data based on their own experience.

This leads to and contributes to the non-standard design of customers.

Jieduobang hereby explains: What you did right last time does not mean that your file is correct! All engineers must pay attention to the design standards and specifications! Jieduobang will once again strictly require all film processing engineers to keep the status quo of customer files as much as possible! Try to handle it according to the design specifications and standards as much as possible, and do not handle it according to the so-called experience! Reflect the problem, so that it can be a reference for all design engineers to improve the design quality and reduce the occurrence of problems!

This article mainly explains conductive holes, key holes, and protel /pads/ and the connection between geber files Conductive hole: via keyhole: Several problems that pads are particularly prone to:

1.Mixing pads and vias leads to problems

2.When your file is pads or protel, send it to the factory and ask for via cover oil.

Be sure to check carefully whether your plug-in hole (pad) also uses via, otherwise your plug-in hole will also be covered with green oil, which will lead to welding failure. Point of dispute: The plug-in hole must be sprayed with tin. How do you cover it with oil? How do I use it? When you say this, please check the file. Is it designed with pads or vias!

Contact us for PCB quote now |

3.When your file is pads or protel, send the file to the factory and place an order requiring via cover oil.

Many customers use pad (plug-in hole) to indicate conductive holes, which leads to your conductive holes opening windows. Maybe you want via cover oil. At that time, the point of dispute may be, what I want is conductive hole cover oil, why is it opened? Then please check your file design! If it is via, treat it as via, if it is pad, treat it as pad! Because no one will know that it is a conductive hole and that is a plug-in hole, and via and pad are the only identifications, please be clear!

4..During the conversion process of via, problems may occur due to non-standard design or unclear setting rules for gerber conversion. When you send a gerber file, the factory manufacturer cannot distinguish which are vias and which are key holes. The only way to identify is to process according to the file. If there is a solder layer, there will be a window! Point of dispute: I want a via cover oil, and you open a window for me now, I may cause a short circuit, so please check your file. The gerber you issued is a film file. The factory has no way to check whether yours is a conductive hole or a key hole. Please check the gerber file to see if there is a solder layer. If there is, open the window, if not, cover it with oil

5.How to design a via cover oil in protel or pads! – This is the most standard practice. If the design is standard, there will be no mistakes!

    In protel, there is a tenting option in the via attribute. If you check it, it must be covered with oil, so what you transfer will be all covered with oil. In pads, the pads transfer file is to cover the via. The method is: when outputting the soldermask, that is, the solder mask layer, just check the upper solder mask top —— the via below, which means that all vias are opened. If it is not checked, the vias are covered with oil. In summary: pads are made according to pads, which are plug-in holes. For vias, you have two choices. If you provide the original file, you can choose when placing an order. If you provide the gerber file, you must check whether the gerber file meets your requirements!

    Contact us for PCB quote now |
