As a Rogers 5880 PCB manufacturer,
Andwin provide high quality Rogers RT duroid 5880 PCB manfucturing,
Rogers 5880 PCB raw material in stock, quickturn delivery is acceptable.

What is Rogers 5880?

Rogers RT duroid 5880 is glass microfiber reinforced PTFE
composites are designed for exacting stripline and microstrip
circuit applications.

The randomly oriented microfibers result in exceptional
dielectric constant uniformity.

The dielectric constant of Rogers RT duroid 5880 laminates
is uniform from panel to panel and is constant over a wide
frequency range.

Rogers 5880 low dissipation factor extends the usefulness of RT duroid
5880 laminates to Ku-band and above.

RT duroid 5880 laminates are easily cut, sheared
and machined to shape.

They are resistant to all solvents
and reagents, hot or cold, normally used in etching printed
circuits or in plating edges and holes.

Normally supplied as a laminate with electrodeposited
copper of 1/4 to 2 ounces/ ft.2 (8 to 70μm) or reverse treated
EDC on both sides,

Rogers 5880 ( RT duroid 5880 ) composites can
also be clad with rolled copper foil for more critical electrical
applications.

Cladding with aluminum, copper or brass plate
may also be specified.

When ordering Rogers 5880 laminates, it is important to specify dielectric thickness,
tolerance, rolled,electrodeposited or reverse treated copper foil,
and weight of copper foil required.

rogers 5880 PCB

Rogers 5880 Features ( RT duroid 5880 specifications )

  • Dielectric constant value of 2.2 at 8GHz to 40GHz.
  • Dissipation Factor value is 0.0004 according 1MHz IPC-TM650,2.5.5.3.
  • Dissipation Factor value is 0.0009 according 10GHz IPC-TM650,2.5.5.5.
  • Thermal Coefficient value is -125 ppm/°C,testing at -15°C to 150°C.
  • Volume Resistivity value is 2×107 Mohm cm according to ASTM D257.
  • Surface Resistivity value is 3 X 107 Mohm cm according to ASTM D257.
  • Specific Heat 0.96 (0.23) is J/g/K (cal/g/C) after be calulated.
  • Tensile Modulus test at 23 C is 1070 (156) MPa (kpsi) and 860 (125)MPa (kpsi)
  • Tensile Modulus test at 100 C is 450 (65) MPa (kpsi) and 380 (55) MPa (kpsi)
  • Rogers 5880 Thermal Conductivity 0.2 W/m/K test in 80C according to ASTM C518
  • Rogers 5880 TD is 500 °C TGA according to ASTM D3850.
  • Density 2.2 gm/cm3 ASTM D792
  • Copper Peel 31.2 (5.5) pli (N/mm)
  • Flammability 94 V-0
  • Lead-Free Process Compatible
rogers 5880 PCB

Rogers 5880 thickness

Rogers RT duroid 5880 thickness standard thickness as follow:

0.005″ (0.127mm) +/- 0.0005″
0.010″ (0.252mm) +/- 0.0007″
0.020″ (0.508mm) +/- 0.0015″
0.031″ (0.787mm) +/- 0.0020″
0.062″ (1.575mm) +/- 0.0030″

Additional thicknesses available from 0.0035″ – 0.375″ in varying increments

Rogers rt duroid 5880 substrate panel sizes

18″x12″ (457x305mm)
18″x24″ (457x610mm)

Additional panel sizes available

Rogers RT duroid 5880 substrate conductor copper use electrodeposited Copper Foil

1/2 oz. (18μm) HH/HH and 1 oz. (35μm) H1/H1

Also,Rolled Copper Foil avaible
1/2 oz. (18μm) 5R/5R
1 oz. (35μm) 1R/1R

Additional claddings, such as heavy metal,
Resistive foil and unclad are available

GET YOUR ROGERS 5880 PCB QUOTE NOW!

Rogers rt duroid 5880 price

Rogers rt duroid 5880 price is very high,from 150 to 600 USD/sheet,

The price depend on the rogers 5880 substrate thickness,copper thickness,
RT duroid 5880 substrate size etc.

Andwin use Rogers 5880 to make mass PCB production,
Many types Rogers rt duroid 5880 in stock,also, have good offer from Rogers factory.
If you need Rogers 5880 PCB or raw material,
Please contact us to get the supper good Rogers rt duroid 5880 price.

Rogers duroid 5880 Some Typical Applications:

  • Commercial Airline Broadband Antennas
  • Microstrip and Stripline Circuits
  • Millimeter Wave Applications
  • Military Radar Systems
  • Missile Guidance Systems
  • Point to Point Digital Radio Antennas
