Rogers RO4835 Laminate

ByGrace

Thermoset laminate materials, including FR-4, are affected by oxidation over
time and temperature. This can slightly increase the dielectric constant and
dissipation factor of the circuit substrate. The change rate and impact on
circuit performance vary based on design and operating temperature. Rogers’
RO4835™ laminate, part of the RO4000® series, offers enhanced stability at
high temperatures and is more resistant to oxidation than other hydrocarbon
materials. RO4835 laminates share similar electrical and mechanical properties
with RO4350B™ laminates and are designed for high frequency performance
and cost-effective circuit fabrication. It uses standard epoxy/glass (FR-4)
processes and is competitively priced.

For frequencies above 500 MHz, RO4000 materials are ideal due to their low
dielectric loss, making them suitable for RF microwave circuits and controlled
impedance transmission lines. The material’s thermal coefficient of expansion
(CTE) matches copper, ensuring excellent dimensional stability and reliable
plated through-hole quality in mixed dielectric multi-layer boards, even under
thermal shock. RO4000 laminates have a Tg of >280°C (536°F), ensuring stable
expansion characteristics throughout circuit processing temperatures.

RO4000 series laminates can be processed using standard FR-4 techniques
without specialized via preparation. They are rigid, thermoset laminates,
compatible with automated systems and scrubbing equipment for copper
surface preparation. RO4835 laminates are RoHS compliant and suitable for UL
94V-0 certified applications.

Fetures of RO4835™ Laminate

  • Significantly improved oxidation resistance compared to typical
  • Thermoset microwave materials
  • Designed for performance sensitive, high volume applications Low loss
  • Excellent electrical performance allows application with higher operating frequencies.
  • Ideal for automotive applications.
  • Tight dielectric constant tolerance
  • Controlled impedance transmission lines
  • Lead-free process compatible
  • No blistering or delamination
  • Low Z-axis expansion
  • Reliable plated through holes
  • Low in-plane expansion coefficient
  • Remains stable over an entire
  • range of circuit processing temperatures

RO4835™ Laminate applications

• Automotive Radar and Sensors
• Point-to point Microwave
• Power Amplifiers
• Phased – Array Radar
• RF Components

RO4835™ Laminate datasheet

RO4835™ Laminate standard thickness

0.0066” (0.17mm) +/- 0.0007”
0.010” (0.25mm) +/- 0.0010”
0.020” (0.51mm) +/- 0.0015”
0.030” (0.76mm) +/- 0.0020”
0.060” (1.52mm) +/- 0.0040”

RO4835™ Laminate standard size

12” X 18” (305 X 457 mm)
24” X 18” (610 X 457 mm)
24” X 36” (610 X 915 mm)
48” X 36” (1219 X 915 mm)

RO4835™ Laminate standard Copper clad

Electrodeposited Copper Foil
1/2 oz. (18μm)
1 oz. (35μm)

ceramic pcb Vacuum deposition equipment

RO4835™ Laminate price

Rogers RO4835™ Laminate price is very high, from 100 to 600 USD/sheet,

The price depend on the rogers  3035 substrate thickness,copper thickness,
Rogers  RO4835™ Laminate substrate size etc.

Andwin use Rogers RO4835™ Laminate to make mass PCB production,
Many types Rogers RO4835™ Laminate are in stock,also, have good offer from Rogers factory.
If you need Rogers RO4835™ Laminateor raw material,
Please contact us to get the supper good Rogers RO4835™ Laminate price.
