Aluminium circuit board
The aluminium layer provides a number of advantages over other materials, including better heat dissipation,
improved electrical conductivity, and greater mechanical strength.
Aluminium circuit boards are commonly used in high-power applications such as LED lighting,
power supplies, and motor controllers, where heat dissipation is a critical factor.
They are also used in applications where weight reduction is important, such as aerospace and automotive industries.
How is the aluminum circuit board formed?
The process of forming an aluminium circuit board involves several steps:
1. Preparing the base material: A thin layer of aluminium is first cleaned and prepared for the circuit board.
2. Applying a layer of insulation: A layer of dielectric material is applied to the surface of the aluminium layer to insulate it from the conductive traces that will be added later.
3. Adding the conductive traces: A layer of conductive material, such as copper, is added to the surface of the dielectric layer in the desired pattern to create the circuit traces.
4. Etching: The excess copper is then etched away, leaving only the desired circuit traces.
5. Drilling: Holes are drilled through the board where components will be mounted.
6. Plating: A layer of metal, such as gold or tin, is plated onto the exposed copper traces to protect them from oxidation and to improve their conductivity.
7. Solder mask: A layer of solder mask is applied to cover the copper traces and protect them from damage during assembly.
8. Silk screen: A silk screen layer is added to label the components and provide other important information.
The final result is an aluminium circuit board that is ready to be populated with electronic components and used in a variety of applications.
Where is the aluminum circuit board used?
Aluminum circuit boards are used in various electronic devices such as LED lights, power supplies,
audio amplifiers, and computer components.
They are also used in industries such as aerospace and automotive for their high thermal conductivity and durability.
