Concept and treatment of residual copper rate in PCB manufacturing
Concept of residual copper rate in PCB manufacturing: The manufacturing process of PCB starts with a PCB “substrate” made of glass epoxy or similar materials. The first step in manufacturing is to light-draw the PCB design wiring for the connection between parts. The method is to use negative transfer (Subtractive transfer) to “print” the circuit film of the designed PCB circuit board on the metal conductor.
This technique is to cover the entire surface with a thin layer of copper foil and eliminate the excess part. If a double-sided board is made, copper foil will be laid on both sides of the PCB substrate. To make a multi-layer board, the two double-sided boards can be “pressed” together with a special adhesive.
Next, the drilling and electroplating required for connecting components can be performed on the PCB board. After the machine equipment drills the holes according to the drilling requirements, the hole wall must be electroplated (Plated-Through-Hole technology, PTH). After the metal treatment inside the hole wall, the internal layers of the circuit can be connected to each other.
Before starting electroplating, the debris in the hole must be cleared. This is because the resin epoxy will produce some chemical changes after heating, and it will cover the internal PCB layer, so it must be cleared first. Both the cleaning and electroplating actions are completed in the chemical process. Next, the solder mask (solder mask ink) needs to be covered on the outermost PCB design wiring, so that the PCB design wiring will not contact the electroplated part.
Then the various component markings are printed on the circuit board to mark the location of each part. It cannot cover any PCB design wiring or gold fingers, otherwise it may reduce the solderability or the stability of the current connection. In addition, if there is a metal connection part, the “gold finger” part is usually plated with gold, so that when inserting the expansion slot, high-quality current connection can be ensured. Finally, it is testing. To test whether the PCB has a short circuit or a break, optical or electronic methods can be used. The optical method uses scanning to find defects in each layer, and electronic testing usually uses a flying probe to check all connections. Electronic testing is more accurate in finding short circuits or open circuits, but optical testing can more easily detect problems with incorrect gaps between conductors.
After the circuit board substrate is completed, a finished motherboard is equipped with various large and small components on the PCB substrate as needed – first use the SMT automatic placement machine to “weld” the IC chip and the patch components, and then manually connect some work that the machine cannot do, and use the wave crest/reflow soldering process to firmly fix these plug-in components on the PCB, so a motherboard is produced.
