RF pcb material rogers
One of their popular products is the Rogers RF PCB material, which is a high-frequency laminate used in the construction of printed circuit boards (PCBs) for wireless communication devices.
The Rogers RF PCB material is made of a ceramic-filled PTFE (polytetrafluoroethylene) substrate with high dielectric constant and low loss tangent.
This material has excellent electrical properties, such as low insertion loss, high isolation, and low signal distortion, making it ideal for high-frequency applications
The Rogers RF PCB material is available in various grades, each with specific electrical and mechanical properties. Some of the popular grades include:
1. RO4000 Series – This is a high-performance laminate with low dielectric constant and low loss tangent. It is suitable for applications up to 10 GHz.
2. RO3000 Series – This is a low-loss laminate with a dielectric constant ranging from 3.38 to 3.66. It is suitable for applications up to 40 GHz.
3. RO4400 Series – This is a high-frequency laminate with a dielectric constant ranging from 3.38 to 6.15. It is suitable for applications up to 77 GHz.
Rogers’ Classification of RF PCB Materials
Rogers Corporation is a leading manufacturer of high-performance printed circuit board (PCB) materials.
They offer a wide range of materials for different applications, including RF and microwave circuits.
rf pcb material rogers who proposed
The Rogers Corporation, a multinational technology company specializing in materials science, is credited with proposing and developing the Rogers PCB material.
The company was founded in 1832 and has been a leader in the development of high-performance materials for various industries, including aerospace, automotive, telecommunications, and electronics.
