Aluminum base pcb board
Aluminum base PCB board, also known as metal core PCB (MCPCB),
is a type of printed circuit board that has a metal core layer made of aluminum or copper.
The metal core provides excellent heat dissipation properties, making it ideal for applications that require high power and high temperature resistance.
Aluminum base PCBs are commonly used in LED lighting, power supplies,
automotive electronics, and other high-power applications.
The metal core layer acts as a heat sink, dissipating heat away from the components on the board and preventing overheating.
The aluminum base PCB board has a number of advantages over traditional FR4 PCBs, including:
1. High thermal conductivity: The metal core layer provides excellent heat dissipation, allowing for higher power applications.
2. High mechanical strength: The metal core layer provides additional mechanical strength, making the board more durable and resistant to damage.
3. Lower thermal expansion: The metal core layer has a lower coefficient of thermal expansion than FR4, reducing the risk of damage due to thermal stress.
4. Improved electrical insulation: The metal core layer provides better electrical insulation than FR4, reducing the risk of short circuits and other electrical issues.
Overall, aluminum base PCBs are a reliable and effective solution for high-power and high-temperature applications that require excellent heat dissipation properties.
