Turnkey PCB assembly service

100% Quality Guarantee or Money back

Automatic Optic Inspection / X-Ray / Functional Test

PCB Assembly products

direct thermal path mcpcb

6 Layers HDI PCB
PCB Size 6X12mm
BGA 0.18mm 3/3 mil Trace
Application: Medical

direct thermal path mcpcb

6 Layers PCB
Heavy Copper 6 OZ
Application: Industry control device

direct thermal path mcpcb

PCB: 2 Layers 2 OZ
Holes copper : 25um
Application: Oil Probing Equipment

direct thermal path mcpcb

8 Layers PCB Via in pad
BGA 0.3mm 0201
Application: Analytical instrument for large equipment

direct thermal path mcpcb

8 Layers High speed PCB
BGA 0.25mm
Application: Industry main Board

Excellent equipment

Better equipments is understructure to do high quality production

Capability package 01005 – 0201 – 0402 – BGA 0.18mm

Automatic solder paste printer

3D SPI (Solder Paste Inspection online)

JUKI FX-3RAL

JUKI KE-2070L

8 Temperature zone reflow oven

RAS-0840

Get professional one stop PCB to assembly solution from us!

How to ensure quality in turnkey PCB Assembly Service?

5 steps to ensure your product 100% are working

1 First Article Inspection (FAI)

FAI can be understood as the first piece quality inspection before the start of mass pcb assembly.

Is to avoid the large quantities defective that because of the process,operation or other reasons.

Each resistor,capacitance and inductance will be inspected by LCR meter.
The chips verified by QC with BOM and Assembly drawing.

2 Automatic Optic Inspection

AOI device is for inspection the compoents placement and solder joint quality after SMT(Surface Mounted Technology).

To achieve better quality control,find and remove the errors early in the assembly process.

It is avoid the defective product to assembly,will avoid scrapping the repairable circuit board.

3 X-Ray inspection

X-ray is a very short wavelength of electromagnetic waves, the wavelength range of 0.0006 a 80nm,
with a strong penetration,X-ray could penetrate a variety of different density of the material.

When the design have BGA or QFN,for checking the solder quality that could not be visible by eyes.

We will use X-ray machine to inspect the BGA or QFN package in finished PCB assembly.

4 Final Quality Assuerance (FQA)

After all the above quality control processes,

Quality Engineer will make final quality visual inspection for the all product.

5 Functional Test

Functional Test are based on automated test tools to simulate a variety of normal, peak and abnormal load
conditions to test the performance of the final PCB assembly products.

Functional Test is a complex process,which include Tool made,Programming and testing,
need technicality support from customer.

Which industry we serve?

High Precision one stop turnkey PCB Assembly Services

  • 12 Years Experienced

  • 300,000 Class Clean Room

  • 4 JUKI production Lines

  • AOI machines

  • X-Ray machine

Get professional one stop PCB to assembly solution from us!

Fill out my online form.
